Tripod2 Quick Start Guide [EN]

Posted on by atmizone

Intro

­

­

i The Tripod2 consists of three distinct sections. The Base section, the Tank section and the Top Cap section.

­

i The Tripod2 features some revolutionary functions, which all include at least one section of the device rotating / moving relatively to the other(s), with a certain mechanism. Please note:

a. All functions require the Tripod2 Base to be fixed and steady.
b. You will need to use two hands for some of the functions. Finger(s) of one hand gripping on a certain section to prevent it from rotating, while finger(s) of the other hand performing the function.

­

­

Vaping mode

­

­

i Grip on Top Cap and screw the Tripod2 on your mod. Rotate the Top Cap clockwise until it can’t rotate any further.

­

­i Liquid slots on Chimney should be fully aligned with the air slots on Base. You are now in Vaping mode.

­

­

Access to deck

­

­

i Grip on Tank section and rotate counter – clockwise on Base section until you feel some resistance [a].

­

i Logo should be fully aligned with the air slots on Base.

­

­i Hold Tank section firmly and pull up [b].

­

­i When tank is full, do the above after turning upside down.­

­

­

Access to airflow

iGrip on Tank section and rotate counter-clockwise on Base section. Keep rotating, past the deck access point [a].­

­

i Lift the Tank section and look from below. The Positive Pole has cut-out slots that secure the AF Tubes in place. Grip on their outer perimeter to twist and pull off the AF Tubes, so as to remove and replace them [b].­

­

iAF Tube 4.0 also serves as nest for the AF Pins.­

­

­

­

Refill

iGrip on Tank section and rotate counter-clockwise on Base section until deck access point [a]. Don’t lift.­

­

iGrip on Tank section to keep it steady and rotate Top Cap counter-clockwise using the other hand, all the way until the stop point. Then pull up gently to remove Top Cap [b].­

­

iRefill through the Seal slots.­

­

­Don’t forget that you can find more info about the Tripod2 in the detailed manual of the device, plus useful tips and media in our support section.

­

­

­

­
